12.1 Dimensions
Name BWT Perla one
Height A mm 797
Width B mm 394
Depth C mm 505
Water inlet connection height D mm 592
Water outlet connection height E mm 652
 F mm 410
Clearance to allow the device cover to be opened G mm 400
Min. sewage system connection DN 40
B
D
A
C
E
F
G
