General
Description
Section 1: General Description
Å
used to put the pump into a low power state when not in use or
back into full power.
Power Jack
You may plug an AC Adapter into the Power jack as an alternate source
of power. e indicator light on the front of the pump will illuminate
when the AC Adapter is in use.
Accessory Jack
is jack is used for accessory cables. See the Instructions for Use supplied
with those accessories.
Air Detector
e Air Detector is on the pump in the area shown in the diagram. If air
is detected in the part of the tubing that passes through the Air Detec-
tor, an alarm sounds and delivery stops. (See Section 5 for Air Detector
specications.) If an Air Detector is not required, it may be turned o.
(See Section 4, Biomed Functions.)
WARNING: When the Air Detector is turned o, the pump will not
detect air in the uid path. Periodically inspect the uid path and
remove any air to prevent air embolism. Air embolism could result in
death or serious injury to the patient.
Cassette
e cassette is the portion of the CADD™ Medication Cassette Reservoir
or CADD™ Administration Set that attaches to the bottom of the pump.
e following single-use products are compatible with the CADD-Legacy®
pump:
• CADD™ Medication Cassette Reservoir (50 or 100 ml), used with the
CADD™ Extension Set
• CADD™ Administration Set
