CADD Legacy Plus 6500 - Page 75

65
Reference
Section 5: Reference
WARNING: e Pump should not be used adjacent to or stacked
with other equipment. If adjacent or stacked use is necessary, the
user should verify normal operation of the pump in the congura-
tion in which it is to be used.
Electromagnetic immunity declaration
The Pump is intended for use in the electromagnetic environment specied below. The
customer or the user of the Pump should assure that it is used in such an environment.
Immunity test IEC 60601
test level
Compliance
level
Electromagnetic environment –
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood, concrete or
ceramic tile. If oors are covered with
synthetic material, the relative humid-
ity should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for
power supply
lines
±1 kV for
input/output
lines
±2 kV for
power supply
lines
Not applicable
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV
dierential
mode
±2 kV
common
mode
±1 kV
dierential
mode
±2 kV
common
mode
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips,
short interrup-
tions and voltage
variations on
power supply
input lines
IEC 61000-4-11
<5 % UT
(>95 % dip
in UT) for 0.5
cycle
40 % UT
(60 % dip in
UT) for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in
UT) for 5 sec
<5 % UT
(>95 % dip
in UT) for 0.5
cycle
40 % UT
(60 % dip in
UT) for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in
UT) for 5 sec
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of the Pump
requires continued operation during
power mains interruptions, it is recom-
mended that the Pump be powered
from an uninterruptible power supply
or a battery.
Power frequency
50/60 Hz) mag-
netic eld
IEC 61000-4-8
3 A/m 400 A/m
(IEC 60601-2-24)
Power frequency magnetic elds
should be at levels characteristic of a
typical location in a typical commer-
cial or hospital environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
