Setup
SETUP
This section provides instruction and guidelines to assemble the simulator and configure the
instructor laptop.
Unpacking the Manikin
The manikin comes in a custom-designed container that provides proper placement for all parts and
accessories.
Follow the guidelines below when opening your shipment:
• Refer to the Unpacking Your CAEManikin document provided in the shipping container to
remove items from the shipping container.
• Exercise extreme caution when using sharp objects, such as a box cutter. A damaged
container can lead to improper storage of the manikin, potentially damaging skin, body
parts, and accessories.
• Reserve a space approximately 2 ft by 6 feet (183 cm) to store the shipping container
before and after use. For more information, see the Care and Maintenance section of this
user guide.
• Verify the content of each item in the container against the shipping paperwork to ensure
you received the correct product and parts.
• Keep original shipping materials, including boxes and foam. Warranty and repair items
must be returned and shipped in their original packaging.
For more information, see the Unpacking Your CAE Manikin in the storage container.
Setup Preparation
To ensure that the manikin is ready for setup and prevent damage to your simulator, it is important
to complete the preparation steps as instructed.
Follow the guidelines below before you begin the setup procedure:
• Prior to using the manikin, ensure it reaches ambient temperature.
• Ensure multi-plug AC power outlets exist in the workspace to charge the simulator and its
powered components. The instructor tablet is battery operated and enabled for wireless
use; however, the patient monitor must be plugged into a power source during use.
• Plug in the tablet, manikin, and rechargeable accessories to a power source using only the
power cords provided. Use the diagram provided in the Unpacking Your CAE Manikin to
identify the designated cords associated with this equipment.
• Do not power on any components unless instructed to do so in the Setup Procedure
section of this guide.
