Using Apollo
6. Connect to the simulator by attaching the end of the IV spike set tubing to
the NOSE, MOUTH or EYES port on the simulator’s left shoulder. Repeat
for each site necessary.
Apollo Prehospital’s Left Shoulder
7. Open the clamp and allow fluid to flow into the simulator.
8. Keep the IV bag attached. Adjust the flow rate manually using the roller clamp.
Note: Cleanup is very important when using simulated fluids. For more information about cleaning
the fluid out of the manikin, see the Care and Maintenance section of this guide.
The NOSE,
MOUTH and
EYES ports
