©2021 CAE 905K690052 v1.0 27
Setup
Aria Power Button LED Color Chart
Aria Battery and Power Scenarios
The % values provided in the table below represent the average battery capacity as represented in
the Maestro UI.
The system powers off (i.e. goes to low power mode, with Blue LED flashing every 30 seconds)
automatically if it is powered on but not running a simulation for 4 hours).
The system sets both batteries to shipping mode (batteries off) if it is in low power mode for 7 days.
Power Button LED Color System State
Flashing blue every second In boatloader mode with update
Flashing blue every second three times In boatloader mode when there is no update
Solid green immediately after bootloader mode In initialization mode
Solid green after initialization mode In running mode, with charger unplugged
Solid orange after initialization mode In running mode, with charger connected
Solid red after initialization mode Battery low or other hardware errors
Flashing blue every 30 seconds In system low-power mode
Flashing green In power-down mode
Flashing red Battery is low and must be charged
Solid red Battery is drained and must be charged
Battery Capacity - Maestro Battery Status Action
Average capacity is larger than 11% Normal The system runs normally.
Average capacity is between 4% and 11% Low The button LED becomes solid Red.
Average capacity is between 0% and 4% Critical The button LED starts blinking Red.
Capacity is 0% Shutdown Set the battery with low capacity to
shipping mode. External power will
need to be plugged in to charge
and operate the system. If both
batteries are in shipping mode, the
manikin shuts down immediately.
