7.2 Set Commands related to channel 'X'
$CMD:SET,CH:X,PAR:ISET,VAL:XXX.X<Cr>
Set Value of current limit
Values of ISET must be passed with correct format (comma and decimal).
7.3 Monitor Commands related to CRATE (channel 6) :
$CMD:MON,CH:6,PAR:CRNAME<Cr>
Readout Crate name : 'NIM8304'
$CMD:MON,CH:6,PAR:PSFREL<Cr>
Readout of the PS Controller Release Firmware
$CMD:MON,CH:6,PAR:PSTEMP<Cr>
Readout value of the PS Controller Temperature
$CMD:MON,CH:6,PAR:FANSP<Cr>
Readout Set value of FAN SPEED (0..6)
$CMD:MON,CH:6,PAR:FAN1<Cr>
Readout value Fan Speed 1 (RPM)
$CMD:MON,CH:6,PAR:FAN2<Cr>
Readout value Fan Speed 2 (RPM)
$CMD:MON,CH:6,PAR:FAN3<Cr>
Readout value Fan Speed 3 (RPM)
$CMD:MON,CH:6,PAR:FUFREL<Cr>
Readout of the FAN UNIT Release Firmware
$CMD:MON,CH:6,PAR:FUTEMP<Cr>
Readout value of the FAN UNIT Temperature
$CMD:MON,CH:6,PAR:FUSNUM<Cr>
Readout value FAN UNIT serial number
$CMD:MON,CH:6,PAR:CRST<Cr>
Readout value Crate status
$CMD:MON,CH:6,PAR:RS232BR<Cr>
Readout Bit Rate RS232 : 0..4
$CMD:MON,CH:6,PAR:CANBR<Cr>
Readout Bit Rate CANBUS : 0..5
$CMD:MON,CH:6,PAR:CANADD<Cr>
Readout Address CANBUS : 0..255
$CMD:MON,CH:6,PAR:IPADD<Cr>
Readout Address IP : xxx.xxx.xxx.xxx
$CMD:MON,CH:6,PAR:IPMSK<Cr>
Readout IP Netmask : xxx.xxx.xxx.xxx
$CMD:MON,CH:6,PAR:IPGTW<Cr>
Readout Gateway : xxx.xxx.xxx.xxx
$CMD:MON,CH:6,PAR:MACADD<Cr>
Readout Mac Address : xx.xx.xx.xx.xx.xx
RS232 Bitrate : 0 -> 9600
1 -> 19200
2 -> 38400
3 -> 57600
4 -> 115200
CanBus Bitrate : 0 -> 1M
1 -> 500K
2 -> 250K
3 -> 100K
4 -> 50K
5 -> 10K
Fan Speed Set : 0 -> Fan Off
1 -> ~1500 Rpm
2 -> ~1800 Rpm
3 -> ~2000 Rpm
4 -> ~2300 Rpm
5 -> ~2600 Rpm
4 -> ~3000 Rpm
Meaning of Crate STATUS bits:
