Caen NIM8304 - Set Commands Related to Crate ( Channel 6)

Document type:
Title:
Revision date:
Revision:
User's Manual (MUT)
Mod. NIM8304 12 slot 7U(5+2) Switching NIM Crate
14/04/2014
3
NPO:
Filename:
Number of pages:
Page:
00121/09:N8304.MUTx/03
NIM8304_REV3.DOC
44
44
Bit 0 -> ON/OFF
1 : Crate ON 0 : Crate OFF
Bit 1 -> PS Alarm
1 : Line ALARM PS active
Bit 2 -> PS Controller Temperature Fail
1 : Temperature on PS Ctr < 5°C or > 65°C
Bit 3 -> PS Temperature Fail
1 : Temperature on PS > 70°C
Bit 4 -> PS OVC
1 : PS in Over Current
Bit 5 -> PS OVV/UNV
1 : PS voltage out of range
Bit 6..8 -> N.C.
Bit 9 -> FAN ON/OFF
1 : FAN ON 0 : FAN OFF
Bit 10 -> Fan 1 Fail
1 : Fan 1 Speed < 10% or > 10% nominal value
Bit 11 -> Fan 2 Fail
1 : Fan 2 Speed < 10% or > 10% nominal value
Bit 12 -> Fan 3 Fail
1 : Fan 3 Speed < 10% o > 10% nominal value
Bit 13 -> Temperature Fail
1 : Temperature FAN < 5°C or > 65°C
7.4 Set Commands related to CRATE (channel6) :
$CMD:SET,CH:6,PAR:ON<Cr>
Crate ON
$CMD:SET,CH:6,PAR:OFF<Cr>
Crate OFF
$CMD:SET,CH:6,PAR:CLR<Cr>
Clear Alarm
$CMD:SET,CH:6,PAR:FANSP,VAL:X<Cr>
Set Fan Speed. Values 0..6
for Fan Speed Set see above.
