Note: Clamping foils works similar to that of HPTLC plates; the
two edges of the foil, left/right, must be inserted underneath the
respective down holders, fig.7.
Fig. 7: Mounting a foil in a foil-holder
4.2. Drying module and plate lift
To attach the plate or foil holder into the drying-module
make sure “LAYER” and substances are facing towards the
inside of the drying module, fig.8.
Fig. 8: Fixation of plate holder in drying module
