Instruction Manual, November 2016 Page 16
used for developing solvent and the right inlet for preconditioning
solvent. The volume of developing solvent should be 10ml, the
preconditioning volume 25ml.
Developing Preconditioning
solvent (10ml) solvent (25ml)
Fig.11: Inlet reservoirs
4.5. Display and function of keys
Control lamps
The control lamps in the display indicate the following status:
• POWER ON: this lamp is lit when the instrument is switched on.
• ON LINE: this lamp is lit when the instrument is ON-LINE with
PC and software.
