Page 30 - Manual FA01554-EN - 01/2021 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Adjusting the partial opening
This determines the partial opening percentage of the M2 leaf with respect to the total travel.
100% = Pedestrian opening
F36 Adjusting the partial
opening
10% to 100% (Default 100%)
Opening slowdown point for M1
Set the percentage of the total travel to be used for M1 opening slowdown.
F37 M1 opening slowdown
point
OFF (Default)
1% to 50%
M1 closing slowdown point
Set the percentage of the total travel to be used for M1 closing slowdown.
F38 M1 closing slowdown
point
OFF (Default)
1% to 50%
M1 opening approach point
Set the percentage of the total travel to be used for M1 opening approach.
F39 M1 opening approach
point
0.5% to 15.0% (Default 8.0%)
M1 closing approach point
Set the percentage of the total travel to be used for M1 closing approach.
F40 M1 closing approach point 0.5% to 15.0% (Default 8.0%)
Opening slowdown point for M2
Set the percentage of the total travel to be used for M2 opening slowdown.
F41 M2 opening slowdown
point
OFF (Default)
1% to 50%
M2 closing slowdown point
Set the percentage of the total travel to be used for M2 closing slowdown.
F42 M2 closing slowdown
point
OFF (Default)
1% to 50%
Opening approach point for M2
Set the percentage of the total travel to be used for M2 opening approach.
F43 M2 opening approach
point
0.5% to 15.0% (Default 8.0%)
Closing approach point for M2
Set the percentage of the total travel to be used for M2 closing approach.
F44 M2 closing approach point 0.5% to 15.0% (Default 8.0%)
