SECONDARY CONTROLS
NOTE: Som e vehicle safety labels are not shown on illustratio ns. For inform ation
on vehicle safety labels, refer to
IMPORTANT ON-PRODUCT LABELS
.
tmo2016-010-168_a
TYPICAL - SECONDARY CONTROLS
1) Ignition Switch and Keys
Ignition Switch
The ignition switc h is located on th e up-
per console area.
tmo2016-010-066_a
1. Ignition switch
tmo2016-010-067_a
IGNITION SWITCH POSITION
1. OFF
2. ACC
3. ON
4. START
OFF
The key can be inserted or removed in
this position only.
In O FF position , the electrical system
of the vehicle is disabled.
The engine is shut down by turning the
ignition switch to OFF position.
_______________
51
