EQUIPMENT
Windshield Position
Windshieldcanbesetto3differentpo-
sitions.
–Closed
– Partially opened (second position on
the handle)
– Fully opened (handle is released)
To close windshield, pull on handle un-
til it closes.
Filling up Windshield Washer
Open cargo box.
Lift service cover and remove wind-
shield washer bottle cap.
219001807-010
Fill windshield washer bottle.
22) Rear Window With
Sliding Opening (Mo dels
with a Cab)
This vehicle comes equipped with a
rear window.
To unloc k rear window, lift side of lock-
ing mechanism and slide window.
tmo2016-010-079_a
1. Rear window
2. Rear window locking mechanism
23) Roof (If Equipped)
For installation and remov al instruc-
tions, see an authorized Can-Am
dealer.
24) Heating System (If
Equipped)
This vehicle comes equipped with a
heating system.
tmo2016-010-085_d
1. Heater fan speed control button
2. Heating level button
Multiple h e atin g vents a re available t o
control air flow in cab.
78
