CHAPTER 2 BASIC OPERATION
2-22
COPYRIGHT © 1999 CANON INC. CANON DADF-B1 REV.0 APR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
3. Sequence of Operations (feeding assembly)
Brake (BK1)
Slow down
CW CW
Slow down
Original leading
edge detected
Original trailing
edge detected
Original leading
edge detected
Original trailing
edge detected
Pre-registration
sensor (U502)
Feed motor (M2)
Registration
sensor OFF
Registration
sensor OFF
(scanning)
(scanning)
Figure 2-227
