Canon imagePROGRAF iPF605 User Manual

Problems Regarding Paper
Problems Regarding Paper
Clearing Jammed Paper (Paper Feed Slot)
Follow these steps to remove any scraps left in the Paper Feed Slot after you clear jammed sheets or
roll paper .
1. Press the Feeder Selection button to activate the Cut Sheet lamp .
2. Press the Load/Eject button.
A screen is displayed for paper type selection.
3. Select POP Board and press the OK button.
A screen is displayed for paper size selection.
4. Select the desired size and press the OK button.
Instructions for feeding POP Board are shown on the Control Panel , but instead of following
them, follow this procedure to remove the jammed paper .
5. Open the T op Cover .
6. Fold an A4 sheet lengthwise four times and insert it through the gap of the Back Cover . Push the
scrap out toward the Platen .
7. Remove the scrap when it is pushed out onto the Platen .
8. If any scraps remain inside the Paper Feed Slot, repeat steps 6 and 7.
9. Close the T op Cover .
10. T urn the printer of f. ( → P .27 )
T roubleshooting 507

Canon imagePROGRAF iPF605 Specifications

General

Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Interface	USB 2.0, Ethernet
Type	Large Format Printer
RAM Installed (Max)	256 MB
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Ink Droplet Size	4 picoliters
Operating Systems	Windows, Mac OS
Media Thickness	0.07 mm to 0.8 mm
Media Types	Plain Paper, Coated Paper, Proofing Paper
