Network Setting
Initializing the Network Settings
Use RemoteUI to restore the network settings to the default values as follows.
Important
Initializing the network settings will also restore the default value of the printer s IP address. As a result,
the RemoteUI page cannot be displayed in the web browser after this procedure.
For instructions on reconguring the IP address, see “Conguring the IP Address on the Printer”.
(→P .417)
For details on RemoteUI , see “Using RemoteUI”. (→P .421)
1. Start the web browser and enter the following URL in the Location (or Address ) box to display
the RemoteUI page.
http:// “printer IP address or name” /
Example: http://xxx.xxx.xxx.xxx/
2. Select Administrator Mode and click Logon .
3. If a password has been set on the printer , enter the password.
4. Click Network in the Device Manager menu at left to display the Network page.
5. Click Reset to Default settings in the lower-right corner of the Network Interface group.
6. After conrming the message, click OK to restore the network settings to the default values.
Note
Y ou can also use imagePROGRAF Device Setup Utility or the Control Panel to restore the default
network settings.
If you use the Control Panel to initialize the network settings, press the Menu button to display MAIN
MENU , and then press , , and to select Interface Setup Ethernet Driver Init. Settings
Y es (in this order), and nally press the OK button.
430 Network Setting
