Canon imagePROGRAF iPF605 User Manual

Handling sheets
Clearing Jammed Paper from the T ray
If a sheet loaded manually becomes jammed, Paper jam. is shown on the Display Screen of the Control
Panel . Remove the jammed paper as follows.
1. Press Load/Eject .
2. Remove the jammed paper .
• If paper is jammed inside the T op Cover
1. Open the T op Cover and move the Carriage to the side manually .
2. Clear any jammed paper from inside the T op Cover .
After removing the paper , make sure there are no other scraps of paper in the printer .
3. Close the T op Cover .
152 Handling Paper

Canon imagePROGRAF iPF605 Specifications

General

Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Interface	USB 2.0, Ethernet
Type	Large Format Printer
RAM Installed (Max)	256 MB
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Ink Droplet Size	4 picoliters
Operating Systems	Windows, Mac OS
Media Thickness	0.07 mm to 0.8 mm
Media Types	Plain Paper, Coated Paper, Proofing Paper
