g.
Paper Alignment Line
An orange line for alignment of paper.
h.
Maintenance Cartridge Cover
Open this cover to replace the Maintenance Cartridge.
i.
Maintenance Cartridge
Absorbs ink used for maintenance purposes such as head cleaning. (Replace the cartridge when it is full.)
j.
Cutter Unit
A round-bladed cutter for automatic roll cutting.
k.
Cutter Rail
The Cutter Unit passes over this rail to cut paper.
l.
Output Tray
All printed documents are ejected from this slot.
m.
Ejection Guide
Guides printed documents as they are ejected.
n.
Top Cover
Open this cover to install the Printhead and remove any jammed paper from inside the printer, as needed. (See "Top
Cover (Inside).") →P.686
o.
Width Guide
When loading the sheets , move the guide to match the paper size.
Note
• The Stand is normally offered as an optional accessory, but it may be provided as a standard accessory in
some sales regions. (See "Stand.") →P.746
