• A Matching Mode
Select the color matching mode to use, as desired.
• B Input Profile Settings
You can select Image, Graphics, or Text. You can choose Matching Method and Input Profile.
Various options are available depending on your selected Matching Mode.
To apply the same input profile automatically for Graphics and Text, select Use the Same Profile for All Ob-
jects. To apply separate input profiles to Graphics and Text, clear Use the Same Profile for All Objects and
specify the individual settings.
• C Printer Profile Settings
Specify the printer profile as desired. Normally, select Auto Settings.
We recommend that you select an ICC profile created using commercially available profile creation software in
order to perform color management accurately on paper other than genuine Canon paper and feed confirmed pa-
per.
The created ICC profile needs to be saved in the following folder on the computer you are using.
C:\Windows\system32\spool\drivers\color folder
Note
• C: may vary according to the user environment.
Note
• For details on settings items, see "Adjusting the Color in the Printer Driver." ➔ P.51
Color Adjustment Sheet: Monochrome
Color Adjustment Sheet: Monochrome
On the Color Adjustment sheet for monochrome printing, you can adjust the brightness and contrast.
Note
• To display the Color Adjustment sheet, on the Main sheet, click Color Settings by Color Mode in Advanced Set-
tings. (See "Main Sheet .") ➔P.167
• A
Sample Type
Choose a sample image from Standard, Portrait, Landscape, or Graphics.
• B
View Color Pattern
Select this checkbox to display the color pattern.
Color Adjustment Sheet: Monochrome
iPF680
User's Guide
Windows Software Printer Driver
176

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
