Canon imagePROGRAF iPF680 User Manual

Media Configuration Tool (Windows)
Media Configuration Tool (Windows)
The Features of Media Conguration Tool ..................................................................................................................404
Installation Procedures .........................................................................................................................................................404
Starting Method ...................................................................................................................................................................... 406
Media
Conguration Tool Main Window ....................................................................................................................... 407
Editing Media Type Information for Genuine Paper and Feed Conrmed Paper ....................................... 407
Adding Media Types ........................................................................................................................................................ 409
Changing Media Names ................................................................................................................................................. 411
Deleting Media Types You Have Added .................................................................................................................. 413
Switching Media Types Display Show/Hide ........................................................................................................... 414
Changing the Display Order of Media Types ........................................................................................................ 416
Checking the update .............................................................................................................................................................417
The Features of Media Configuration Tool
The Features of Media Configuration Tool
In imagePROGRAF, the best printer settings for each paper are collected together in media information files in order to
give the highest quality printing results. Settings for Canon genuine paper and Canon feed confirmed paper are provi-
ded by Canon in these media information files.
Note
• Canon genuine paper and Canon feed confirmed paper are detailed in the Paper Reference Guide.
The Media Configuration Tool allows you to perform the following tasks.
• When supported paper has been newly added to the printer, you can add that media type to the printer control
panel and printer driver by using the media information file provided by Canon.
• You can rearrange lists of the types of paper on the printer control panel and in printer driver dialog boxes and
rename them, in addition to other functions.
Important
• Normally, the Media Configuration Tool is installed and the media information is configured when you install the printer
driver from the User Software CD-ROM. Use this software if you want to add new media information or edit existing
media information.
• Administration of paper information using the Media Configuration Tool should be performed by the printer administra-
tor.
Drivers Applicable with Media Configuration Tool
• imagePROGRAF Printer Driver
Installation Procedures
Installation Procedures
The Media Configuration Tool installation screen appears when you start the installation of a new version of the Media
Configuration Tool. The installation procedure started from this screen is described below.
Important
• If the printer driver is installed from the User Software CD-ROM, the Media Configuration Tool is also installed and the
media information is also configured. Therefore, the following procedure does not normally need to be performed. To
install the Media Configuration Tool without using the User Software CD-ROM, such as when you have downloaded a
new version of the Media Configuration Tool from the Canon website, use the following procedure.
• You must be logged in as Administrator when installing software in Windows.
The Features of Media Conguration Tool
iPF680
User's Guide
Handling and Use of Paper Media Conguration Tool (Windows)
404

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
