The following settings are available for automatic cutting.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
None After printing completes, the roll is not cut per page, and the next page of data is printed
successively.
Print Cut Guideline After printing completes, a line is printed per page, and the next page of data is printed suc-
cessively.
J Mirror
Specify whether to print a mirror image, as needed. Select this option to print a version of the document or image with
the left and right sides inverted.
View set. Dialog Box for the Printing Application
View set. Dialog Box for the Printing Application
In the View set. dialog box, you can check details of the selected printing application.
Note
• To display the View set. dialog box, on the Main pane, click View set. by Print Target. (See "Main Pane .") ➔ P.281
• A Print Target
Shows all Print Target options (settings items for the printing application).
• B Name
Identifies the item selected in Print Target by its name and an icon.
• C
Details
Here, you can confirm detailed settings values for each item selected in the Print Target list.
Matching pane
Matching pane
On the Matching pane, you can specify color matching to compensate for differences in the appearance of colors on
various devices.
Important
• The Matching pane is not displayed when No color correction or Monochrome is selected in Color Mode.
View set. Dialog Box for the Printing Application
iPF680
User's Guide
Mac OS Software Printer Driver
286

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
