Initial Settings
Initial Settings
Conguring the IP Address on the Printer .................................................................................................................. 488
Conguring the IP Address Using imagePROGRAF Device Setup Utility ................................................ 500
Conguring the IP Address Using the Printer Control Panel ........................................................................ 488
Conguring the IP Address Using ARP and PING Commands ..................................................................... 489
Conguring TCP/IPv6 Network Settings ...................................................................................................................... 491
Conguring the Printer Driver Destination (Windows) ........................................................................................... 491
Conguring the Printer Driver Destination (Mac OS) ............................................................................................. 492
Conguring the Printer's TCP/IP Network Settings With RemoteUI ................................................................ 492
Configuring the IP Address on the Printer
Configuring the IP Address on the Printer
You must configure the printer's IP address before using the printer in a TCP/IP network.
The printer's IP address is configured automatically when you install the printer driver following the instructions in the
Setup Guide.
Configure the IP address by using imagePROGRAF Device Setup Utility, the printer Control Panel, or ARP or PING
commands, if the IP address is changed, or if you change the printer connection mode to a network connection. For
details on configuring the IP address, refer to the following topics.
• Configuring the IP Address Using imagePROGRAF Device Setup Utility ➔ P.500 (Windows)
• Configuring the IP Address Using the Printer Control Panel ➔ P.488
• Configuring the IP Address Using ARP and PING Commands ➔ P.489
Important
• If you use a DHCP server for automatic assignment of the printer's IP address, printing may no longer be possible
after the printer is turned off and on. This is because an IP address different from before has been assigned. Thus,
when using DHCP server functions, consult your network administrator and configure the settings in one of the follow-
ing ways.
• Configure the setting for dynamic DNS updating
In the printer menu, either set DNS Dync update to On, or activate the setting Enable DNS Dynamic Update in
RemoteUI.
(See "Menu Settings.") ➔P.456
(See "Configuring the Printer's TCP/IP Network Settings With RemoteUI.") ➔P.492
• Configure the setting for assignment of the same IP address each time the printer starts up
Note
• We recommend configuring the printer's IP address even if you will use the printer in networks other than TCP/IP net-
works. Configuring the printer's IP address enables you to use RemoteUI to configure the network settings and man-
age the printer with a web browser.
For details on RemoteUI, see "Using RemoteUI." ➔ P.486
Configuring the IP Address Using the Printer Control Panel
Configuring the IP Address Using the Printer Control Panel
This topic describes how to configure the printer's IP address on the Control Panel.
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab ( ).
Conguring the IP Address on the Printer iPF680
User's Guide
Network Setting Initial Settings
488

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
