I Set
Click to display the Color Settings dialog box for more advanced color settings.
Adjusting the Color in the Printer Driver P.51
J Unidirectional Printing
Select this checkbox to prevent problems such as misaligned lines and improve the print quality. However, the
printing speed becomes slower.
Q Thicken Fine Lines
Select this check box to print fine lines more distinctly.
P Sharpen Text
Select this check box to print text more sharply.
S Reduce Print Unevenness
Select this checkbox for two-pass printing to reduce color shading.
This option is displayed if you have selected Plain Paper in Media Type and Office Document in Print Priority.
Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box
The Paper Detailed Settings dialog box offers the following settings. For details on settings items, refer to the printer
driver help.
Note
To display the Paper Detailed Settings dialog box, on the Main pane, click Set by Media Type. (See "Main
Pane .") P.281
A Media Type
The paper selected with Media Type of the Main panel is displayed.
For information on the types of paper the printer supports, refer to the Paper Reference Guide. (See "Displaying the
Paper Reference Guide.")
P.363
B Drying Time
Specify the time that the printer waits for ink to dry, as needed. The Between Pages setting is only valid for rolls.
Paper Detailed Settings Dialog Box
iPF680
User's Guide
Mac OS Software Printer Driver
284

Table of Contents

Other manuals for Canon imagePROGRAF iPF680

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF680 and is the answer not in the manual?

Canon imagePROGRAF iPF680 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Matte black, Yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Page description languagesGARO, HP-GL/2, HP-RTL
Media thickness0.07 - 0.8 mm
Maximum print size-
Maximum roll length18 m
Media width (rolls)254 - 609.6 mm
Media width (sheets)203.2 - 609.6 mm
Maximum roll diameter150 mm
Paper tray media typesCoated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)A1, A2, A3
ISO B-series sizes (B0...B9)B2, B4
CertificationRoHS
Product colorBlack, Grey
Sound pressure level (printing)47 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet LAN data rates10/100/1000 Base-T/TX Mbit/s
Ethernet interface typeGigabit Ethernet
Compliance industry standardsIEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)0.5 W
Power consumption (typical)140 W
Storage temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth757 mm
Width997 mm
Height507 mm
