Canon imagePROGRAF iPF680 User Manual

Note
• For an overview of the media types, see "Types of Paper." ➔P.360
• For details on how to select the media type in the control panel and printer driver, see "Types of Paper." ➔ P.360
Choosing General-Purpose Paper Settings
Since these settings anticipate a wide variety of paper other than genuine Canon paper and feed confirmed paper,
these settings will make it difficult for bleeding ink and the printhead rubbing to occur. Refer to the following table for
the relationships between the conditions of the paper other than genuine Canon paper and feed confirmed paper and
the media type to select.
Type Approximate weight Approximate thickness Printer control panel Printer driver
Plain Paper 70 g/m² 0.09 mm (0.0035 in.) Plain Paper Plain Paper
Coated Paper 90 g/m² 0.13 mm (0.0051 in.) LW. Coated Paper Lightweight Coated Paper
170 g/m² 0.22 mm (0.0087 in.) HW. Coated Paper Heavyweight Coated Paper
Photo Paper 180 g/m² 0.18 mm (0.0071 in.) LW. Photo Paper Lightweight Photo Paper
LWPhotoPaper(LI)(*1) Lightweight Photo Paper (LowInk)(*1)
260 g/m² 0.26 mm (0.010 in.) HW. Photo Paper Heavyweight Photo Paper
HWPhotoPaper(LI)(*1) Heavyweight Photo Paper (LowInk)(*1)
Proof 80 g/m² 0.10 mm (0.0039 in.) News Proof (*2)
Sign/CAD Paper 150 g/m² 0.11 mm (0.0043 in.) CAD Clear Film CAD Clear Film
90 g/m² 0.08mm (0.0031 in.) CAD Trce(LowInk) CAD Tracing Paper (Low Ink)
100 g/m² 0.13 mm (0.0051 in.) Syn.Papr(LowInk) Synthetic Paper (LowInk)
*1: Print using slightly less ink. Try this if you are concerned about rubbing of ink after printing.
*2: Software RIP is required separately.
Selecting Special Settings
Special settings are provided that allow you to select the amount of ink used in steps. You can fix lackluster colors or
bleeding ink by selecting special settings where the amount of ink used is suitable for the paper you are using.
"Special 1" uses the least amount of ink, with the amount of ink used increasing through 5 steps as the number increa-
ses up to "Special 5" which uses the greatest amount of ink. Although colors become more vivid as the amount of ink
used increases, bleeding also occurs more easily. We recommend that you try in order starting from "Special 1" while
checking the state of the printing.
Displaying the Paper Reference Guide
Displaying the Paper Reference Guide
The Paper Reference Guide are not included. To view, display the Paper Reference Guide on the website from the
links in the installed software. An Internet connection is required in order to view them.
• Windows
The basic instructions for displaying the Paper Reference Guide from the printer driver are as follows.
1. Open the printer driver.
(See "Accessing the Printer Driver Dialog Box from Applications (Windows).") ➔ P.164
(See "Accessing the Printer Driver Dialog Box from the Operating System Menu (Windows).") ➔ P.165
iPF680
Displaying the Paper Reference Guide
User's Guide
Handling and Use of Paper Paper
363

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
