Canon imagePROGRAF iPF680 User Manual

• B Set
Click to display one of the following dialog boxes depending on the selection in A Page Layout. In these dialog
boxes, you can specify layout details and which pages to print, as well as other settings.
• Page Layout Printing
• Pages to Print
• Free Layout Settings
• C Watermark
Activating this option makes two settings available, Watermarks and D Edit Watermark.
• Printing With Watermarks ➔P.145
• Watermarks
Lists the provided watermarks. Choose the watermark to print.
• D Edit Watermark
Click to display the Edit Watermark dialog box for creating your own, original watermark.
• E Print Centered
Activate this setting to print document images in the center of the paper.
• Printing Originals Centered on Rolls ➔ P.126
• Printing Originals Centered on Sheets ➔ P.130
• F Rotate 180 degrees
Activate this option to rotate document images by 180 degrees before printing.
• G No Spaces at Top or Bottom (Conserve Paper)
Activate this setting to print the next image skipping blank areas above and below printable data in documents,
which enables you to conserve the paper.
• Conserving Roll Paper by Printing Originals Without Top and Bottom Margins ➔ P.139
• H Copies
Enter the number of copies to print, in a range of 1–999.
• Reverse Order
Activate this option to print pages in reverse order.
• Collate
Activate this option to print complete sets in the specified quantity.
• I Page Options
Click to display the Page Options dialog box, which enables you to complete settings for printing the user name,
date, or page number in the header or footer.
• Page Options Dialog Box ➔ P.183
• J
Special Settings
If the printing results are not as you expected, click this option to display the Special Settings dialog box and
change how printing is processed.
• Special Settings Dialog Box ➔ P.184
• S
Defaults
Click to restore all settings on the sheet to the default values.
Layout Sheet
iPF680
User's Guide
Windows Software Printer Driver
182

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
