Canon imagePROGRAF iPF680 User Manual

Important
• If the imagePROGRAF Print Plug-In toolbar/ribbon is not displayed, refer to the following.
• When Print Plug-In for Office is not displayed ➔P.239
3
Check that the imagePROGRAF Print Plug-In toolbar/ribbon is
displayed.
4 Click the buttons on the toolbar/ribbon according to the items you want to set.
Icon Contents
Menu
Displays the About, Help, and Special Settings dialog boxes. (See "Configuring Special
Settings.") ➔P.274
Printer list
Select Printer.
If you select Show All Printers, the imagePROGRAF printers will be displayed again. Se-
lect this when you want to display all printer drivers or update the display.
PrintButton
The print Wizard is displayed.
The settings Print Entire Sheet and Print Selected Area can be set.
Printing Wizard dialog box
Important
• If you want to change the display to another file or application while the Printing Wizard is open, close the
Printing Wizard dialog box. Otherwise, you may not be able to change displays or operate the toolbar/
ribbon.
• The Printing Wizard will not start if you click the Print button on the toolbar/ribbon while editing a cell.
• When more than one worksheet is selected, the Printing Wizard cannot be run. Select only one worksheet
and click Print again.
• When an object is selected, the Printing Wizard is not started if you click the Print button on the toolbar/
ribbon.
• If the paper size in Excel is blank, the Printing Wizard cannot be run. From the File menu in Excel, select
Page Setup and check Paper size.
iPF680 To start from Microsoft Excel
User's Guide
Windows Software Print Plug-In for O󱐰ce
267

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
