Canon imagePROGRAF iPF680 User Manual

The Layout menu will appear automatically.
Important
• If the range selected in Excel 2007 or later is too large, it will not be possible to analyze the data. Select a
smaller range and then run the analysis.
Note
• If data analysis requires time, a message dialog will appear. If you select No, you will return to the application.
5 Select Roll Paper Width that is set in the printer.
6 Select image size.
7 Select layout.
8 To configure Binding, click the Binding Settings button.
Refer to "Configuring Binding (Excel)" ➔ P.273 for details on the procedure for configuring Binding.
9
Select Next.
10
Select Media Type.
11
Enter Copies.
Print Selected Area(Excel) iPF680
User's Guide
Windows Software Print Plug-In for O󱐰ce
272

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
