Setting Details
Fit Roll Paper Width Enlarges/reduces the whole page automatically to fit the width of the roll paper with the page
width.
*Make sure that the width of the roll paper in the printer is set correctly for Roll Paper Width
in the Paper Settings panel.
*Displayed only if rolls are selected in Paper Source.
Scaling Enlarges/reduces the whole page by the scaling rate as specified. Input the scaling value in
numerical characters. You can specify a range between 5 and 600%.
*You can change the numbers by clicking either ▲ button or ▼ button.
*Although Scaling can be set to make the image larger than the media size, the part that
does not fit in the media cannot be printed.
*This is not displayed when a checkmark is placed in Borderless Printing.
•
Borderless Printing
You can print the media without margins on all sides when the roll paper with the specific width and the specific
media type is used.
For more information about Borderless Printing, see "Print with No Borders." ➔ P.312
Note
• Available only if rolls are selected in Paper Source.
• This is not displayed when a checkmark is placed in Print Centered.
• Paper Size
You can select the size of the print media.
Note
• This is not displayed when Fit Roll Paper Width is set in Enlarged/Reduced Printing.
• Print Centered
You can print on the center of the media loaded in the printer.
For more information about Print Centered, see "Print on the Center." ➔ P.313
Note
• This is not displayed when a checkmark is placed in Borderless Printing.
• No Spaces at Top or Bottom
You can save paper on not to feed roll paper for the empty spaces when the print data contains spaces at the top
or bottom.
For more information about No Spaces at Top or Bottom, see "Not Print Spaces at the Top/Bottom." ➔P.313
Note
• Available only if rolls are selected in Paper Source.
•
Rotate Page
Select the method for rotating page.
The following settings are available for rotating page.
Setting Details
Rotate Right 90 Degrees Rotates the portrait page right 90 degrees and print in landscape orientation. When the rota-
ted page can fit in the width of roll paper, the page is rotated automatically, and when it can
not fit in the width of roll paper, the page is not rotated.
Rotate Left 90 Degrees Rotates the portrait page left 90 degrees and print in landscape orientation. When the rotated
page can fit in the width of roll paper, the page is rotated automatically, and when it can not fit
in the width of roll paper, the page is not rotated.
Rotate 180 degrees Allows you to rotate the image 180 degrees from the vertical to the right.
iPF680
Output Settings Panel
User's Guide
Mac OS Software Preview
303

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
