Chapter 3

3-4

a. LEVEL 0

Moving the printer on the same floor without difference in grade

Transportation procedure

1) Turn off the power and check that the heads are capped.

2) Open the upper cover and mount the belt stopper.

F-3-7

When mounting the belt stopper, be careful not to move the carriage by applying too much pressure. If the carriage moves when the heads are capped, the rubber

part of the cap may touch the nozzles on the heads and damage the print head.

3) Close the upper cover.

4) Remove the paper and roll holder.

5) Remove power cord and interface cable.

6) Unlock the casters on the stand and move the printer slowly.

If the printer is subjected to strong vibrations when it is moved, it can cause ink leakage or damage to the print head. Be sure to move the printer slowly and carefully.

Item Description

[Prep. MovePrinter] on the Main menu This need not be performed.

Allowed tilting angle Do not tilt.

Ink consumption No ink is consumed.

Ink tank It may be installed or removed.

Separation of main unit and stand They do not need to be separated.

Maintenance cartridge Install.

There is no need to open a new maintenance cartridge.

Replacement of consumable parts There is no need to replace consumable parts.

Service support No service support is necessary.
