Chapter 3
3-5
b. LEVEL 1
Moving the printer on a floor with difference in grade or by truck
Transportation procedure
1) If there is a message instructing to replace the maintenance cartridge or check the remaining ink, replace the maintenance cartridge.
2) Remove the paper and roll holder.
3) From [Set/Adj. Menu] > [Prep. MovePrinter], select [LEVEL 1].
4) Press the [OK] key and perform [LEVEL 1] MOVE PRINTER.
5) If the consumable parts counter is checked and a message to replace consumable parts appear, check the consumable parts counter from service mode and replace
the necessary consumable part.
See "d. Replacing consumable parts during transportation."
Repeat [LEVEL 1] after replacing consumable parts and resetting the counter.
6) When MOVE PRINTER completed message appears, turn off the power, and remove the power cord and interface cable.
7) Open the upper cover and raise the ejection guide.
F-3-8
Item Description
[Prep. MovePrinter] on the Main menu Perform [LEVEL 1].
Allowed tilting angle Lengthwise: -30 to +30 degrees
Rotation: -10 to +10 degrees
Ink consumption No ink is consumed.
Ink tank It may be installed or removed.
Separation of main unit and stand They do not need to be separated.
Maintenance cartridge Install.
There is no need to open a new maintenance cartridge.
However, if there is a message instructing to replace the maintenance cartridge or check the remaining ink,
replace with new maintenance cartridge before transporting.
Replacement of consumable parts Replacement of consumable parts and resetting of counter may be necessary.
Service support If consumable parts must be replaced, service support is necessary.
To Next Page
