Chapter 3
3-6
8) Remove the ejection support and lower the ejection guide.
F-3-9
9) Install the belt stopper.
F-3-10
When mounting the belt stopper, be careful not to move the carriage by applying too much pressure. If the carriage moves when the heads are capped, the rubber
part of the cap may touch the nozzles on the heads and damage the print head.
10) Close the upper cover.
11) Attach the cushioning materials and tape.
12) Unlock the casters on the stand and move the printer slowly.
If the printer is subjected to strong vibrations when it is moved, it can cause ink leakage or damage to the print head. Be sure to move the printer slowly and carefully.
To Next Page
