Canon imagePROGRAF iPF8400 Service Manual

Chapter 6
6-8
T-6-20
T-6-21
24 VMGND - GND
25 VMGND - GND
J3501
Pin Number Signal name IN/OUT Function
1GND -GND
2 H1-C-DATA-4-OD_OUT OUT Odd head(L) data signal 4(C)
3GND -GND
4 H1-A-DATA-1-OD_OUT OUT Odd head(L) data signal 1(A)
5GND -GND
6 H1-B-HE-2_B OUT Head(L) heat enable signal 2(B)
7GND -GND
8 H0-D-DATA-7-OD_B OUT Odd head(R) data signal 7(D)
9GND -GND
10 H0-E-HE-8_B OUT Head(R) heat enable signal 8(E)
11 GND - GND
12 H0-E-DATA-8-OD_B OUT Odd head(R) data signal 8(E)
13 GND - GND
14 H0-F-DATA-10-OD OUT Odd head(R) data signal 10(F)
15 GND - GND
16 H0-E-DATA-9-OD_B OUT Odd head(R) data signal 9(E)
17 GND - GND
18 H0-F-HE-10_B OUT Head(R) heat enable signal 10(F)
19 GND - GND
20 H0-F-DATA-11-OD OUT Odd head(R) data signal 11(F)
21 GND - GND
22 H0-F-HE-11_B OUT Head(R) heat enable signal 11(F)
23 GND - GND
24 H0-F-DATA-11-EV_B OUT Even head(R) data signal 11(F)
25 GND - GND
26 H0-F-DATA-10-EV_B OUT Even head(R) data signal 10(F)
27 GND - GND
28 H0-E-HE-9_B OUT Head(R) heat enable signal 9(E)
29 GND - GND
30 H0-E-DATA-9-EV_B OUT Even head(R) data signal 9(E)
31 GND - GND
32 H-DASH_LICC2_B OUT Head analogue switch A/D trigger signal
33 GND - GND
34 H0-A-DATA-0-OD_B OUT Odd head(R) data signal 0(A)
35 GND - GND
36 H0-A-DATA-1-OD_B OUT Odd head(R) data signal 1(A)
37 GND - GND
38 H0-B-HE-2_B OUT Head(R) heat enable signal 2(B)
39 GND - GND
40 H0-B-DATA-2-OD_B OUT Odd head(R) data signal 2(B)
41 GND - GND
42 H0-B-DATA-3-OD_B OUT Odd head(R) data signal 3(B)
43 GND - GND
44 H0-C-HE-4_B OUT Head(R) heat enable signal 4(C)
45 GND - GND
46 H0-C-DATA-4-OD_B OUT Odd head(R) data signal 4(C)
47 GND - GND
48 H0-A-HE-0_B OUT Head(R) heat enable signal 0(A)
49 GND - GND
50 VHT_MONI IN VHT controll signal
J3502
Pin Number Signal name IN/OUT Function
1GND -GND
2 H0-E-DATA-8-EV_B OUT Even head(R) data signal 8(E)
J3401
Pin Number Signal name IN/OUT Function
