Canon imagePROGRAF iPF8400 Service Manual

Chapter 6
6-9
T-6-22
3 OUT_ENB OUT Head data enable signal
4 H0-D-HE-7_B OUT Head(R) heat enable signal 7(D)
5 GND - GND
6 H0-D-DATA-7-EV_B OUT Even head(R) data signal 7(D)
7 GND - GND
8 H0-D-DATA-6-EV_B OUT Even head(R) data signal 6(D)
9 GND - GND
10 H0-D-DATA-6-OD_B OUT Odd head(R) data signal 6(D)
11 GND - GND
12 H0-D-HE-6_B OUT Head(R) heat enable signal 6(D)
13 GND - GND
14 H0-C-HE-5_B OUT Head(R) heat enable signal 5(C)
15 GND - GND
16 H0-C-DATA-5-OD_B OUT Odd head(R) data signal 5(C)
17 GND - GND
18 H0-DSOUT2 OUT Head(R) temperature output signal 2
19 GND - GND
20 H0-DSOUT1 OUT Head(R) temperature output signal 1
21 GND - GND
22 H0-DLD_LICC2 OUT Head(R) analogue switch latch signal
23 H0-DATA_LICC2 OUT Head(R) analogue switch data signal
24 H0-DASLK_LICC2 OUT Head(R) analogue switch clock signal
25 GND - GND
26 H0_CLK_B OUT Head(R) clock signal
27 GND - GND
28 H0_LT_B OUT Head(R) latch signal
29 GND - GND
30 H0-C-DATA-5-EV_B OUT Even head(R) data signal 5(C)
31 GND - GND
32 LIFT_CAM_IN IN Lift cam sensor output signal
33 GND - GND
34 H0-B-HE-3_B OUT Head(R) heat enable signal 3(B)
35 GND - GND
36 H0-C-DATA-4-EV_B OUT Even head(R) data signal 4(C)
37 GND - GND
38 H0-B-DATA-3-EV_B OUT Even head(R) data signal 3(B)
39 GND - GND
40 H0-B-DATA-2-EV_B OUT Even head(R) data signal 2(B)
41 GND - GND
42 H0-A-DATA-1-EV_B OUT Even head(R) data signal 1(A)
43 GND - GND
44 H0-A-HE-1_B OUT Head(R) heat enable signal 1(A)
45 GND - GND
46 H0-A-DATA-0-EV_B OUT Even head(R) data signal 0(A)
47 GND - GND
48 VH_CHARGE0 OUT VH leakage detection ON/OFF signal 0
49 VH_CHARGE1 OUT VH leakage detection ON/OFF signal 1
50 GND - GND
J3601
Pin Number Signal name IN/OUT Function
1 GND - GND
2 ENCODER_B IN Carriage encoder output signal B
3 ENCODER_A IN Carriage encoder output signal A
4 /CR_COVER IN Carriage cover sensor output signal
5 GND - GND
6 H-DASH_LICC2_B OUT Head analogue switch A/D trigger signal
7 GND - GND
8 H1-D-DATA-7-OD_B OUT Odd head(R) data signal 7(D)
9 GND - GND
10 /H1-E-HE-8_B OUT Head(R) heat enable signal 8(E)
11 GND - GND
J3502
Pin Number Signal name IN/OUT Function
