Canon imagePROGRAF iPF8400 Service Manual

Chapter 6
6-15
T-6-28
33 H0-F-HE-10_B OUT Head(R) heat enable signal 10(F)
34 GND - GND
35 H0-E-DATA-9-OD_B OUT Odd head(R) data signal 9(E)
36 GND - GND
37 H0-F-DATA-10-OD OUT Odd head(R) data signal 10(F)
38 GND - GND
39 H0-E-DATA-8-OD_B OUT Odd head(R) data signal 8(E)
40 GND - GND
41 H0-E-HE-8_B OUT Head(R) heat enable signal 8(E)
42 GND - GND
43 H0-D-DATA-7-OD_B OUT Odd head(R) data signal 7(D)
44 GND - GND
45 H1-B-HE-2_B OUT Head(L) heat enable signal 2(B)
46 GND - GND
47 H1-A-DATA-1-OD_OUT OUT Odd head(L) data signal 1(A)
48 GND - GND
49 H1-C-DATA-4-OD_OUT OUT Odd head(L) data signal 4(C)
50 GND - GND
J105
Pin Number Signal name IN/OUT Function
1 GND - GND
2 VH_CHARGE1 OUT VH leakage detection ON/OFF signal 1
3 VH_CHARGE0 OUT VH leakage detection ON/OFF signal 0
4 GND - GND
5 H0-A-DATA-0-EV_B OUT Even head(R) data signal 0(A)
6 GND - GND
7 H0-A-HE-1_B OUT Head(R) heat enable signal 1(A)
8 GND - GND
9 H0-A-DATA-1-EV_B OUT Even head(R) data signal 1(A)
10 GND - GND
11 H0-B-DATA-2-EV_B OUT Even head(R) data signal 2(B)
12 GND - GND
13 H0-B-DATA-3-EV_B OUT Even head(R) data signal 3(B)
14 GND - GND
15 H0-C-DATA-4-EV_B OUT Even head(R) data signal 4(C)
16 GND - GND
17 H0-B-HE-3_B OUT Head(R) heat enable signal 3(B)
18 GND - GND
19 LIFT_CAM_IN IN Lift cam sensor output signal
20 GND - GND
21 H0-C-DATA-5-EV_B OUT Even head(R) data signal 5(C)
22 GND - GND
23 H0_LT_B OUT Head(R) latch signal
24 GND - GND
25 H0_CLK_B OUT Head(R) clock signal
26 GND - GND
27 H0-DASLK_LICC2 OUT Head(R) analogue switch clock signal
28 H0-DATA_LICC2 OUT Head(R) analogue switch data signal
29 H0-DLD_LICC2 OUT Head(R) analogue switch latch signal
30 GND - GND
31 H0-DSOUT1 OUT Head(R) temperature output signal 1
32 GND - GND
33 H0-DSOUT2 OUT Head(R) temperature output signal 2
34 GND - GND
35 H0-C-DATA-5-OD_B OUT Odd head(R) data signal 5(C)
36 GND - GND
37 H0-C-HE-5_B OUT Head(R) heat enable signal 5(C)
38 GND - GND
39 H0-D-HE-6_B OUT Head(R) heat enable signal 6(D)
40 GND - GND
41 H0-D-DATA-6-OD_B OUT Odd head(R) data signal 6(D)
J104
Pin Number Signal name IN/OUT Function
