Canon imagePROGRAF iPF8400 Service Manual

Chapter 6
6-16
T-6-29
T-6-30
T-6-31
T-6-32
42 GND - GND
43 H0-D-DATA-6-EV_B OUT Even head(R) data signal 6(D)
44 GND - GND
45 H0-D-DATA-7-EV_B OUT Even head(R) data signal 7(D)
46 GND - GND
47 H0-D-HE-7_B OUT Head(R) heat enable signal 7(D)
48 OUT_ENB OUT Head data enable signal
49 H0-E-DATA-8-EV_B OUT Even head(R) data signal 8(E)
50 GND - GND
J201
Pin Number Signal name IN/OUT Function
1 ENCODER_B IN Linear encoder sensor output signal B
2GND -GND
3 ENCODER_A IN Linear encoder sensor output signal A
4 SNS_5V OUT Power supply(+5V)
J202
Pin Number Signal name IN/OUT Function
1 SNS_5V OUT Power supply(+5V)
2GND -GND
3 /CRCOVER IN Carriage cover sensor output signal
J701
Pin Number Signal name IN/OUT Function
1 H3V OUT Power supply
2 VH1_FB IN VH1 feed back voltage
3 VH1 OUT Power supply
4 VH1 OUT Power supply
5 VH1 OUT Power supply
6 VH1 OUT Power supply
7 VH1 OUT Power supply
8 VH1 OUT Power supply
9GND -GND
10 GND - GND
11 GND - GND
12 GND - GND
13 GND - GND
14 GND - GND
15 GND - GND
16 VH2 OUT Power supply
17 VH2 OUT Power supply
18 VH2 OUT Power supply
19 VH2 OUT Power supply
20 VH2 OUT Power supply
21 VH2 OUT Power supply
22 VH2_FB IN VH2 feed back voltage
23 VHT OUT Power supply
24 GND - GND
25 GND - GND
J702
Pin Number Signal name IN/OUT Function
1GND -GND
2GND -GND
3GND -GND
4 H1-B-DATA-3-EV OUT Even head(L) data signal 3(B)
J105
Pin Number Signal name IN/OUT Function
