Canon imagePROGRAF iPF8400 Service Manual

Chapter 7
7-18
OUTPUT 5
F-7-15
OUTPUT 6
F-7-16
MEMO:
- Displays all "?" if "GAP CALIB" is not performed.
- If the value exceeds 1000, 999 is displayed.
Display
position
Description
1 Media edge (diffuse reflection) media output (including outside light)
2 Media edge (diffuse reflection) outside light output (when LED is OFF)
3 Media edge (diffuse reflection) platen output (excluding outside light)
4 Media edge (diffuse reflection) gain
5 Media edge (diffuse reflection) current value (Unit: X10mA)
6 Media edge (regular reflection) media output (including outside light)
7 Media edge (regular reflection) outside light output (when LED is OFF)
8 Media edge (regular reflection) platen output (excluding outside light)
9 Media edge (regular reflection) gain
10 Media edge (regular reflection) current value (Unit: X10mA)
11 GAP_Far media output (including outside light)
12 GAP_Far outside light output (when LED is OFF)
13 GAP_Far platen output (excluding outside light)
14 GAP_Far gain
15 GAP_Far current value (Unit: X10mA)
16 GAP_Near media output (including outside light)
17 GAP_Near outside light output (when LED is OFF)
18 GAP_Near platen output (excluding outside light)
19 GAP_Near gain
20 GAP_Near current value (Unit: X10mA)
21 Density (red) media output (including outside light)
22 Density (red) outside light output (when LED is OFF)
23 Density (red) platen output (excluding outside light)
24 Density (red) gain
25 Density (red) current value (Unit: X10mA)
26 Density (green) media output
27 Density (green) outside light output (including outside light)
28 Density (green) platen output (excluding outside light)
29 Density (green) gain
30 Density (green) current value (Unit: X10mA)
31 Density (blue) media output (including outside light)
32 Density (blue) outside light output (when LED is OFF)
33 Density (blue) platen output (excluding outside light)
34 Density (blue) gain
35 Density (blue) current value (Unit: X10mA)
XXXXXXXXX XXXXXX
OUT PUT 5
26 26 26 27 27 27 28 28 28 29 29 29
30
30 30
XXXXXXXXX XXXXXX
OUT PUT 6
31 31 31 32 32 32 33 33 33 34 34 34
35
35 35
