Chapter 7

7-32

2) UGW Address [UGW-ADDRESS] and UGW port [UGW-PORT]

Usually, the default values set in advance are used for the setting value of [UGW-ADDRESS] and [UGW-PORT]. Unless there is a special instruction, the default

value should not be changed. If it should be changed, the communication with UGW may have an error. If [UGW-ADDRESS] and [UGW-PORT] are changed, the

new setting will be enabled after power OFF/ON.

Therefore, usually, the setup is not necessary.

* If you change under a special instruction, perform the following procedure.

(1) Setting address for UGW

- In service mode, referring to the "Service Mode Menu Tree", go to [UGW-ADDRESS] menu using key and key.

F-7-31

- Press key to enter the Setup Mode. (A character indicating the input mode (in the upper right corner of the screen) and the cursor are displayed.)

Enter UGW address (URL).

F-7-32

Display to indicate an input mode

A: Alphabet capital letter

a: Alphabet small letter

1: Numerical character

- The cursor is shown at the first letter.

- Use and keys to select characters to enter.

- Press [Back] key to cancel what you entered and go back to the previous screen.

- Press [OK] key to determine what you entered and go back to the previous screen.

(2) Setting up the GW Port Number

- In service mode, referring to the "Service Mode Menu Tree", go to [UGW-PORT] menu using key and key.

F-7-33

- Press key to enter the Setup Mode. (A cursor is displayed.)

Enter a port number.

F-7-34

- Use and keys to select characters to enter.

- Press [Back] key to cancel what you entered and go back to the previous screen.

- Press [OK] key to determine what you entered and go back to the previous screen.

* The actual setting value of UGW address [UGW-ADDRESS] and UGW port [UGW-PORT] are categorized as confidential information, so they are not described

in this manual.

3) Communication Test [COM-TEST]

(1) In service mode, referring to the "Service Mode Menu Tree", go to [COM-TEST] menu using key and key.

F-7-35

(2) Press [OK] key to start the test. ("=" is displayed at the start of the test.)

F-7-36

(3) During the communication test, "CHECK NOW" is displayed.

F-7-37

UGW ADDRESS

E- RDS

UGW A D DR ES S

http://
