Chapter 8
8-7
Use another paper.
Press Online to clear the error.
03010000-2F33 Unadjustable because of transparent media Replace with adjustable media.
Paper loaded askew.
Lift the release lever.
03016000-2010 Skew Correct the skew in the paper and reload it.
Ink tank cover is open.
Turn off printer, wait a while, and turn it
on again.
03031000-2E10 Ink tank cover abnormally open Close the ink tank cover and turn on the printer again.
Carriage Cover is open.
Turn off printer, wait a while, and turn it
on again.
03031000-2E11 Printhead cover open Close the carriage cover and turn off the printer, and turn
it on again.
Rel lever is in wrong position.
Turn off printer, wait, then turn on again.
03031000-2E12 Release lever open Close the release lever and turn off the printer, and turn
it on again.
Rel lever is in wrong position.
Turn off printer, wait, then turn on again.
03031000-2F21 Pinch roller open error Check the pinch roller unit and surrounding part.
Top cover is open.
Turn off printer, wait a while, and turn it
on again.
03031000-2F38 Top cover abnormally open Close the top cover and turn on the printer again.
! Unable to detect ink level correctly. 03031101-25B7 With ink tank cover open, ink has
diminished below the pin check level.
During printing with ink tank cover open,
the ink has diminished below the pin check
level.
*Under study as a part of stop-less supply
system. This error is intended for
preventing the ink tank to be installed in
other model (iPF710) using the same ink
tank by the hardware configuration that
disables writing to ink tank EEPROM
while ink tank cover is open.
By closing the ink tank cover, this warning is cleared.
If the pin check tank is removed in this condition, the
error changes to the pin check tank removal error. Or, if
printing is continued in this condition, and the subtank
corresponding to the pin check tank is detected empty,
the error changes to the subtank corresponding to pin
check tank empty error.
! Paper mismatch
Make sure media type and paper size
match for the adjustment print.
03060000-2E20 Paper type mismatch at adjustment Choose the same paper type as the first page and
perform adjustment printing.
Sheet printing is selected.
Press Load/Eject and load sheets.
03060100-2E02 After starting to print sheet, no manual
feeding paper has been detected.
Load cut sheet in manual feeding slot.
Sheet printing is selected.
Press Load/Eject and load sheets.
03060100-2E04 No front manual feed paper Load cut sheet in the front manual feed paper slot.
Sheet printing is selected.
Press Load/Eject and load sheets.
03060100-2E05 After starting to print sheet, no manual
feeding paper has been detected.
Load cut sheet in manual feeding slot.
Sheet printing is selected.
Press Load/Eject and load sheets.
03060200-2E03 No cassette paper Load cut sheet in the cassette.
Cassette printing is selected.
Press Load/Eject and remove manually
03060200-2E0B After manual feed cut sheet had been
loaded, data with cassette specification was
received.
Load cut sheet in the cassette.
Roll printing is selected.
Press Load/Eject and load a roll.
03060A00-2E00 Data with a roll media specification has
been received but no roll media are loaded.
Load roll media.
Roll printing is selected.
Press Load/Eject and load a roll.
03060A00-2E01 No roll paper at internal printing Load roll media.
PaprWidth Mismatch
Plain Paper
ISO A3
Online=Print
Stop=Stop Printing
03060A00-2E08 Paper width mismatch Check the paper width and print.
No Roll Feed Unit.
Turn printer off and install roll feed unit.
03060A00-2E0E Roll media unit not installed. Install the roll media unit.
The roll is empty.
Lift the release lever and replace the roll.
03060A00-2E1B Roll media end Renew the supply of roll media.
Roll feed unit err
Turn off printer and check roll feed unit
03060A00-2E24 Roll cam sensor error Check the roll paper unit.
Roll Paper
Plain Paper
ISO A3
Load Roll Paper
Stop Printing
03060A00-2E33 Roll media is not loaded when receiving
the printing job.
Roll paper is not loaded when a job with
roll paper specification has been received.
(1) Choose [Load Roll Paper] and load paper according
to the panel guidance.
(2) Choose [Stop Printing] or press the Stop button to
stop printing.
(3) Lift the release lever, and load paper.
! Roll2 (Lower) printing is selected.
Press Load/Eject and load a roll.
03060A00-2E34 Roll paper is not loaded. (lower roll) (1) Choose [Load Roll Paper] and load paper according
to the panel guidance.
(2) Choose [Stop Printing] or press the Stop button to
stop printing.
(3) Lift the release lever, and load paper.
Roll printing is selected.
Press Load/Eject and load a roll.
03060A00-2E35 Roll media is not loaded for internal
printing.
Reload the roll media.
Display message Code* Condition detected Action
To Next Page
