Canon imagePROGRAF TM-355 Online Manual

Detect image size
Specifies the output object area method that provides efficient printing, which avoids parts of images being
cut off when HP-GL/2 data does not include image drawing range information.
Display this item by selecting the following.
(Setup) > Printer settings > Print settings > HP-GL/2 print settings > Processing options
TM-355/TM-255/TM-5355/TM-5255
• OFF•
◦ If image drawing range information is included in HP-GL/2 data:◦
The output object area is in accordance with the image drawing range information.
The origin specified by the image drawing range information is drawn in the upper-left corner of the
paper.
◦ If image drawing range information is not included in HP-GL/2 data:◦
The output object area uses the printer's maximum roll paper width as the horizontal dimension and
1.5 times the maximum roll paper width as the vertical dimension.
Even though the particular page included in multiple pages does not contain a command which
specifies the image drawing range, note that the image drawing range specified for the just previous
page is applied if previous pages contain the command.
• Command priority•
◦ If image drawing range information is included in HP-GL/2 data:◦
The output object area is in accordance with the image drawing range information.
The origin specified by the image drawing range information is drawn in the upper-left corner of the
paper.
◦ If image drawing range information is not included in HP-GL/2 data:◦
Applies the minimum image range detected as the output object area.
The upper left corner of the detected minimum image range is drawn in the upper left corner of the
paper.
• Detected size•
Applies the minimum image range detected as the output object area.
Image drawing range information included in HP-GL/2 data is not used.
The upper left corner of the detected minimum image range is drawn in the upper left corner of the
paper.
Note
• If part of an image is being cut off or if an image is out of alignment, try using each of the settings in the
following sequence: OFF, Command priority, Detected size.
423
