A: Top Cover
Open this cover to install the print head and remove any jammed paper from inside the printer, as
needed.
Top Cover (Inside)
B: Roll Paper Cover
Open this cover to load rolls.
Roll Paper Cover (Inside)
C: Width Guide
When loading the sheets , move the guide to match the paper size.
D: Paper Alignment Line
A white line for alignment of paper.
E: Ink Tank Cover
Open this cover to replace the ink tank.
TM-340/TM-240/TM-5340/TM-5240 have space to store spare ink tanks inside the left cover.
Ink Tank Cover (Inside)
F: Operation Panel
Use this screen to operate the printer and check the printer status. The angle of the screen can be
adjusted freely.
Operation Panel
G: Release Lever
When releasing the Paper Retainer, push this lever back.
H: USB flash drive port
Insert a USB flash drive to this port.
I: Output Guide
Supports output paper.
J: Maintenance Cartridge Cover
Open this cover to replace the maintenance cartridge.
Maintenance Cartridge Cover (Inside)
K: Printer Stand
A stand that holds the printer. Equipped with casters to facilitate moving it.
Printer Stand
