5. Select Manual.5.
A confirmation message appears.
Note
• If you do not perform Auto (advanced), a confirmation message prompting you to perform Auto•
(advanced) appears. In this case, select Yes and perform Auto (advanced).
6.
Select Yes.
6.
The paper source setting screen appears.
7.
Select Roll paper or Manual.
7.
A test pattern is printed for adjustment.
8.
Select D-1.
8.
9.
Examine adjustment test pattern D-1 and select the number with straight lines.
9.
A: Example with straight lines
B: Example with misaligned lines
Note
• If two patterns seem equally good and you cannot decide which one is better, choose an•
intermediate value. For example, choose 11 if you cannot decide whether pattern 10 or 12 is
better.
10.
Repeat steps 8-9 to specify adjustment values for D-2 and other remaining patterns.
10.
Specify all the items displayed on the touch screen.
11.
Select OK.
11.
The adjustment value is now registered, and adjustment is complete.
557
