Chapter 1
1-3
1.2.5 Roll Feed Unit
0013-2512
Roll Feed Unit
The roll feed unit is optionally available to use roll media with this printer.
F-1-6
Roll holder set
This set consists of roll holder, holder stopper, 3-inch paper tube attachment, and borderless printing spacer (commonly used for 2-inch paper tube and 3-inch paper
tube).
[Roll holder]
F-1-7
[Holder stopper](for 2-inch paper tube and 3-inch paper tube)
F-1-8
[3-inch paper tube attachment]
F-1-9
[Borderless printing spacer]
F-1-10
MEMO:
A borderless printing spacer is used to perform borderless printing on A1-size (594 mm) and A2-size (420 mm) roll media. This printer is furnished with a number
of borderless printing ink receiving channels on the platen to address multi-sized borderless printing needs. Borderless printing on A1 or A2-size roll media is made
possible by using a spacer, without needing to produce a new borderless printing ink receiving channel.
