Canon iPF605 - External Covers

Chapter 4
4-3
4.3.4 External Covers
0019-6233
a) Left/right circle cover
Removing the left/right circle cover
1) When removing the left circle cover [1], turn it in the direction of the arrow.
F-4-4
2) When removing the right circle cover[1], turn it in the direction of the arrow.
F-4-5
[1]
[1]
