4.4 Applying the Grease
4.4.1 Applying the Grease
0019-6268
Some parts require application of grease when replaced. Apply the grease(special tool) listed below.
Smear the grease lightly and evenly with a flat brush or the like.
For the printer disassembly/reassembly method, refer to "DISASSEMBLY/REASSEMBLY" and "parts catalog".
Do not apply the grease to locations in which not designated grease may cause poor print quality. Take particular care that grease do not get onto the wiper, cap,
and linear scale.
No. Location Grease type Quantity
1 Joint base Molykote PG-641 Approx.6/12mg
2 Shaft cleaner/oil pad EU-1 soaks enough.
3 Eject roller bearing Molykote PG-641 Approx.12mg
4
Eject roller center bearing Molykote PG-641 Approx.12mg
5 Spur cam Molykote PG-641 Approx.20mg
6 Pinch roller unit release shaft Molykote PG-641 Approx.12mg
