7.1.2 Map of the Service Mode
0019-6274
The hierarchy of menus and parameters in the Service mode is shown below.
T-7-1
First Level Second Level Third Level Fourth Level Fifth Level
DISPLAY PRINTINF YES/NO : Select YES to execute
print
SYSTEM S/N
TYPE
LF TYPE
TMP
SIZE LF
SIZE LF
SIZE CR
SIZE CR
HEAD S/N
LOT
INK C
---
BK
WARNING 1
---
20
ERROR 1
---
20
INK CHECK 000000
I/O DISPLAY I/O DISPLAY 1
I/O DISPLAY 2
ADJUST PRINT PATTERN NOZZLE 1 : Press the [OK] button to
execute
NOZZLE 2 : Press the [OK] button to
execute
NOZZLE 3 : Press the [OK] button to
execute
OPTICAL AXIS : Press the [OK] button to
execute
LF & HAKUSYA
SENSOR CHECK
HEAD ADJ. MANUAL HEAD ADJ DETAIL : Press the [OK]
button to execute
BASIC : Press the [OK]
button to execute
ADJ. SETTING A A-1 : Adjustment value
entry
---
A-24 : Adjustment value
entry
---
F F-1 : Adjustment value
entry
SAVE SETTINGS YES/NO
RESET SETTINGS YES/NO
NOZZLE CHK POS. YES/NO
GAP CALIB. YES/NO
REPLACE CUTTER YES/NO
