Canon iPF605 - Page 193

Chapter 4
4-55
c) Spur unit
5) Spur cam
F-4-114
d) Pinch roller unit
6) Pinch roller unit release shaft
F-4-115
Molykote PG-641
Approx. 20mg
Molykote PG-641
Approx. 12mg
(Five location A2 (17") model
and seven location A1 (24") model)
