Chapter 1
1-7
Firmware Flash ROM (update from USB or Ethernet, IEEE1394)
- Printer description language
GARO (Graphic Arts language with Raster Operation), HP-GL/2, HP
RTL
Interface USB2.0, Ethernet, IEEE1394 (option)
Operation panel LCD (160 X 128 dots), 12 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean, Russianand
and Japanese
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead [PF-03] Number nozzles: 2560 nozzles per color
Ink tank [PFI-102]MBK,BK,C, M, Y
Capacity: 130 ml per color (Ink tanks supplied with the printer contain
90 ml of each color.)
Detection functions (Cover
system)
Detects opening/closing of the top cover and ink tank cover.
Detection functions (Ink passage
system)
Detects presence/absence of ink tank, ink level (dot count and electrode),
presence/absence of the maintenance cartridge, waste ink full level,
presence/absence of the printhead, and opening/closing of the supply
valve.
Detection functions (Carriage
system)
Detects the ambient temperature, head temperature, presence/absence of
the head, and no ink ejection.
Detection functions (Paper path
system)
Detects presence/absence of paper, cutter position, leading/trailing edge
of paper, paper width, and skew.
Operating noise During printing: Approx. 49 dB (A) or less
During standby: Approx. 35 dB (A) or less
Operating environment Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80% without dew condensation
Print quality guaranteed
environment
Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH
Power supply 100-120 VAC (50/60 Hz), 220-240 VAC (50/60 Hz)
Power consumption (Maximum) During printing: Max. 100 W
Power consumption In power save (sleep) mode: 5W or less(220-240 VAC: 6W or less)
(When IEEE1394 board installed, 10W or less[220-240 VAC: 11W or
less])
During standby: 1 W or less
Printer unit dimensions
(WxDxH)
997 x 670 x 344 mm
With stand (option): 997 x 870 x 993 mm
Weight Approx. 45 kg
