T-6-22
24 VH IN Power supply (+21.5V)
25 GND - GND
26 GND - GND
27 GND - GND
28 GND - GND
29 GND - GND
30 GND - GND
J22
Pin Number Signal name IN/OUT Function
1 GND - GND
2 ENCODER_A OUT Linear encoder output signalA
3 SNS_5V IN Power supply (+5V)
4 ENCODER_B OUT Linear encoder output signalB
5 SNS_5V IN Power supply (+5V)
6 H1-C-DATA-4-OD IN Odd head L data signal 4(C)
7 GND - GND
8 H1-C-HE-4 IN Head L heat enable signal8(E)
9 GND - GND
10 H1-B-DATA-3-OD IN Odd head L data signal 3(B)
11 GND - GND
12 H1-B-DATA-2-OD IN Odd head L data signal 2(B)
13 GND - GND
14 MLT_SNS_2IN OUT Multi sensor signal2
15 MLT_SNS_1IN OUT Multi sensor signal1
16 GND - GND
17 PWLED1_ON IN Multi sensor LED 1 drive signal
18 PWLED2_ON IN Multi sensor LED 2 drive signal
19 PWLED3_ON IN Multi sensor LED 3 drive signal
20 PWLED4_ON IN Multi sensor LED 4 drive signal
21 GND - GND
22 H1-DSOUT1 OUT Head L temperature output 1
23 H1-DSOUT2 OUT Head L temperature output 2
24 GND - GND
25 H1-DASLK LICC2 IN Head L analogue switch clock signal
26 H1-DATA LICC2 IN Head L analogue switch data signal
27 H1-DLD LICC2 IN Head L analogue switch latch signal
28 H1-E-DATA-9-EV IN Even head L data signal9(E)
29 GND - GND
30 H1-E-HE-9 IN Head L heat enable signal9(E)
31 GND - GND
32 H1-F-DATA-10-EV IN Even head L data signal10(F)
33 GND - GND
34 H1-F-DATA-11-EV IN Even head L data signal11(F)
35 GND - GND
36 H1-F-HE-11 IN Head L heat enable signal11(F)
37 GND - GND
38 H1-F-DATA-11-OD IN Odd head L data signal 11(F)
39 GND - GND
40 H1-F-HE-10 IN Head L heat enable signal10(F)
41 GND - GND
42 H1-E-DATA-9-OD IN Odd head L data signal 9(E)
43 GND - GND
44 H1-F-DATA-10-OD IN Odd head L data signal 10(F)
45 GND - GND
46 H1-E-DATA-8-OD IN Odd head L data signal 8(E)
47 GND - GND
48 H1-E-HE-8 IN Head L heat enable signal8(E)
49 GND - GND
50 H1-D-DATA-7-OD IN Odd head L data signal 7(D)
J21
Pin Number Signal name IN/OUT Function
