Chapter 6
6-12
10 H1-A-HE-1 OUT Head L heat enable signal 1(A)
11 VH OUT Power supply (+21.5V)
12 VH OUT Power supply (+21.5V)
13 VH OUT Power supply (+21.5V)
14 VH OUT Power supply (+21.5V)
15 VH OUT Power supply (+21.5V)
16 H1-E-DATA-9-OD OUT Odd head L data signal 9(E)
17 H1-F-HE-11 OUT Head L heat enable signal11(F)
18 H1-E-DIA1 IN Heal L DI sensor signal 1(E)
19 H1-D-DIA1 IN Heal L DI sensor signal 1(D)
20 HEAD_3V OUT Power supply (+3V)
21 HEAD_3V OUT Power supply (+3V)
22 H1-B-DATA-3-EV OUT Even head L data signal 3(B)
23 H1-A-DATA-0-EV OUT Even head L data signal 0(A)
24 H1-B-HE-2 OUT Head L heat enable signal 2(B)
25 VH OUT Power supply (+21.5V)
26 VH OUT Power supply (+21.5V)
27 H1-D-DIA2 IN Heal L DI sensor signal 2(D)
28 H1-E-HE-8 OUT Head L heat enable signal8(E)
29 H1-E-DIA2 IN Heal L DI sensor signal 2(E)
30 H1-F-DIA2 IN Heal L DI sensor signal 2(F)
31 H1-E-HE-9 OUT Head L heat enable signal9(E)
32 H1-D-DATA-7-EV OUT Even head L data signal 7(D)
33 H1-D-HE-6 OUT Head L heat enable signal 6(D)
34 H1-C-DATA-5-0D OUT Odd head L data signal 5(C)
35 H1-C-DATA-4-EV OUT Even head L data signal 4(C)
36 H1-A-DATA-1-EV OUT Even head L data signal 1(A)
37 H1-A-DIA2 IN Heal L DI sensor signal 2(A)
38 H1-B-DIA2 IN Heal L DI sensor signal 2(B)
39 H1-C-HE-4 OUT Head L heat enable signal8(E)
40 H1-D-DATA-7-OD OUT Odd head L data signal 7(D)
41 H1-E-DATA-8-OD OUT Odd head L data signal 8(E)
42 H1-F-HE-10 OUT Head L heat enable signal10(F)
43 H1-F-DATA-11-EV OUT Even head L data signal11(F)
44 H1-F-DATA-8-EV OUT Even head L data signal 8(F)
45 H1-D-DATA-6-EV OUT Even head L data signal 6(D)
46 H1-C-DIA2 IN Heal L DI sensor signal 2(C)
47 H1-C-DATA-5-EV OUT Even head L data signal 5(C)
48 H1-B-DIA1 IN Heal L DI sensor signal 1(B)
49 H1-A-HE-0 OUT Head L heat enable signal 0(A)
50 H1-B-DATA-2-OD OUT Odd head L data signal 2(B)
51 H1-B-DATA-3-OD OUT Odd head L data signal 3(B)
52 H1-C-DATA-4-OD OUT Odd head L data signal 4(C)
53 GND - GND
54 GND - GND
55 GND - GND
56 H1-F-DATA-11-OD OUT Odd head L data signal 11(F)
57 H1-E-DATA-9-EV OUT Even head L data signal9(E)
58 GND - GND
59 H1-D-DATA-6-OD OUT Odd head L data signal6(D)
60 H1-C-HE-5 OUT Head L heat enable signal 5(C)
61 H1-B-HE-3 OUT Head L heat enable signal 3(B)
62 H1-A-DIA1 IN Heal L DI sensor signal 1(A)
63 H1-A-DATA-1-OD OUT Odd head L data signal1(A)
64 GND - GND
65 GND - GND
66 GND - GND
67 GND - GND
68 H1-F-DATA-10-OD OUT Odd head L data signal 10(F)
69 H1-F-DIA1 IN Heal L DI sensor signal 1(F)
70 H1-D-HE-7 OUT Head L heat enable signal 7(D)
71 GND - GND
72 H1-CLK OUT Head L clock signal
73 H1-LT OUT Head L latch signal
74 H1-B-DATA-2-EV OUT Even head L data signal 2(B)
J24
Pin Number Signal name IN/OUT Function
