c) ADJUST
Performs adjustments and prints the adjustment and check patterns necessary for adjusting the printer parts.
1) PRINT PATTERN
T-7-12
LF & HAKUSYA and SENSOR CHECK are intended for factory adjustment purposes.
No adjustment by service personnel is required.
2) HEAD ADJ.
Set or initialize the registration adjustment values of each printheads.
T-7-13
3) NOZZLE CHK POS.
This mode for adjusting the optical axis of the head management sensor. For details, refer to "Disassembly/Reassembly" > "Adjustment and Setup Items" > "Pro-
cedure after replacing the head management sensor".
4) GAP CLIB.
This mode measures the gap between the printhead and media by multi sensor and corrects the calibration value.
Display Description
NOZZLE 1 Prints the nozzle check pattern by single direction/ single pass without using the non-
discharging back up.
It is used to check for the non-discharging nozzles.
- Media size: A4
- Media type: any
NOZZLE 2 Print a 100% solid print pattern (used to check the ink reaction that cannot be checked with
"NOZZLE 1") in the single path direction. Use this method when checking blocked nozzles.
- Use paper with a height equal to or longer than that of A4-sized paper (in portrait orientation).
- Any media type is acceptable.
NOZZLE 3 Print a 100% solid print pattern (used to check the ink reaction that cannot be checked with
"NOZZLE 1") in the single path direction. Use this method when checking blocked nozzles.
(The print drive control method is different from that for "NOZZLE 2".)
- Use paper with a height equal to or longer than that of A4-sized paper (in portrait orientation).
- Any media type is acceptable.
OPTICAL AXIS Prints the pattern and adjusts the optical axis of the multi sensor.
For details, refer to "Disassembly/Reassembly" > "Adjustment and Setup Items" > "Procedure
after replacing the carriage unit or multi sensor".
- Media type: photo glossy paper
LF & HAKUSHA * For Factory
SENSOR CHECK * For Factory
Display Description
MANUAL HEAD ADJ DETAIL Prints the detail patterns for the manual head adjustment.
After printing, the mode will change to [ADJ. SETTING]. Check the printed patterns and input the set values.
BASIC Prints the basic patterns for the manual head adjustment.
After printing, the mode will change to [ADJ. SETTING]. Check the printed patterns and input the set values.
ADJ. SETTING A to F A-1 to F-1 This mode is to input the registration adjustment values.
It is possible to return the values to the former one by printing the status print before changing the value.
SAVE SETTINGS Save the registration adjustment values that has been input.
RESET SETTINGS Initialize the registration adjustment values (to 0).
